Is a Compact Balanced-to-Balanced Diplexer a good Differential Mode?
- Posted by Aintzane Lujambio Genua
- On October 14, 2021
- 0
A compact balanced-to-balanced diplexer composed of two balanced bandpass filters is proposed in this letter. The balanced filters are implemented using compact edge-coupled square split-ring resonators. The design methodology is based on the standard coupled-resonators filter synthesis procedure.
