DLA Qualified Fixed Film Chip Resistor (MIL-PRF-55342) | News
- Posted by Emilio Cano García
- On October 17, 2020
- 0
The changes in the edition 8th September of DLA QPL-55342 Qualified Product List (QPL) are detailed herein below:
Group with re-scope (the scope of the qualification group is changed):
- Resistors included in the detailed specification MIL-PRF-55342/11 from Mini-Systems, with tolerance 0.5%, have expanded the qualified range:
- Min Value: 10Ω to 1Ω
- Max Value: 1MΩ to 8MΩ
| wdt_ID | GOVERNMENT DESIGNATION | MANUFACTURER'S DESIGNATION | QUALIFICATION REFERENCE | SPECIFICATION SHEET | SUPPLIER\'S NAME |
|---|---|---|---|---|---|
| 1 | |||||
| 4 | Char. K, L, M; res. values 1 ohms thru 8 megohms; res. tols. .5 pct.; terms. B, C, D, G, T, U, W; product levels C, M, P, R, S, T, U, V |
MSR20, WA20 | 55342-118-92; 55342-1353-05; 55342-155-00; 55342-1851-86; 55342-1854-86; 55342-24-80 |
11 | Mini-Systems, Inc. |
| 7 |
Removal groups
- All groups of detail specification MIL-PRF-55342/4 from IRC have been removal. This change has already been implemented in the last edition (Jun 2, 2020). The following illustration shows the affected groups:
| wdt_ID | GOVERNMENT DESIGNATION | MANUFACTURER'S DESIGNATION | QUALIFICATION REFERENCE | SPECIFICATION SHEET | SUPPLIERS NAME |
|---|---|---|---|---|---|
| 1 | Char. E, H, K, M; res. values 10 ohms thru 470 kilohms; res. tols. 5, 10 pct.; terms. B; product levels C, M, P, R, S, T Char. E, H, K, M; res. values 10 ohms thru 499 kilohms; res. tols. 1 pct.; terms. B; product levels C, M, P, R, S, T Char. E, H, K, M; res. values 100 ohms thru 500 kilohms; res. tols. .1 pct.; terms. B; product levels C, M, P, R, S, T |
W1505R-07 | 55342-104-96; 55342-150-95; 55342-295-89; 55342-3029-10 |
4 | IRC, Inc. |
