Panasonic Adds 0603 Size to its Anti-Sulfurated, Anti-Surge Thick Film Chip Resistors
- Posted by doEEEt Media Group
- On March 18, 2020
- 0
Panasonic miniaturize its anti-sulfurated, anti-surge thick film chip resistors by new 0603 small case size series ERJ UP3.
Features
- High resistance to sulfurization achieved by adopting Anti-Sulfurated electrode material (Ag-Pd-based inner electrode) and structure
- ESD surge characteristics superior to standard metal film resistors
- High reliability… Metal glaze thick film resistive element and three layers of electrodes
- Suitable for both reflow and flow soldering
- High power …… 0.25 W:0603 inch / 1608 mm size
- Reference Standard … IEC 60115-8,JIS C 5201-8,JEITA RC-2134C
- AEC-Q200 compliant
- RoHS compliant
