Satellite SAOCOM 1A

Satélite Argentino de Observación Con Microondas

Alter Technology has been working together with CONAE, INVAP and VENG providing engineering, testing and logistics services in the supply and quality control of the highly reliable electronic components used in the SAOCOM project. In addition to these activities, the company has made an exhaustive control of the manufacturers during the production of the components and has been supporting in the search of solutions to the technical and logistical problems encountered during the manufacture of the components or the integration of the same in the teams.

The main objective of SAOCOM 1A and for which this satellite of more than 3 tons is launched into space, is to observe the Earth and operationally obtain measurements of soil moisture, so that emergency applications, such as the detection of spills of hydrocarbons in the sea or monitoring of flood coverage. But we can also talk about agrarian objectives since it will allow this sector to benefit from the images, about 200 per day, that the satellite will collect from space.

Objectives of  SAOCOM 1A

This first satellite was launched into orbit from the Vandenberg Base on October 7h of 2018. The second is foreseen on March 2020, of the United States Air Force, on the coast of California, by the Falcon 9 rocket, from SpaceX. The main objectives of the mission corresponding to the SAR space radar capabilities (Synthetic Aperture Radar – or “synthetic aperture” -) polarimetric band developed by Argentine engineers to operate onboard the SAOCOM satellites:

• Provide information on the Symmetric Aperture Radar (SAR) polarimetric band regardless of the weather conditions and the time of day, from different areas of the earth, in real-time and in stored mode, with a spatial resolution between 10 and 100 meters and with different viewing angles.
• Obtain specific products derived from SAR information, particularly maps of soil moisture, which represents a great help for agriculture, hydrology and for the health area, due to its proven socio-economic impact.
• Satisfy the applications considered in the Space Information Sectors of the Argentine National Space Plan.

It is expected that soil moisture maps will be obtained over an area of ​​more than 83 million hectares of the Pampas region of Argentina in short periods of 6 days. Due to the importance of these maps for the agricultural sector, they are called strategies since they have an important socioeconomic impact.

The central applications to this project can be divided into three, where two of them are directed to agriculture and a third to hydrology, of which the following general objectives should be highlighted:

• provide support to agricultural producers in the decision-making process related to planting, fertilization and irrigation, in crops such as soybean, corn, wheat and sunflower, for example, to optimize the use of fertilizers,
• provide support to agricultural producers in relation to the use of agrochemicals (fumigation) for the control of diseases in crops, in particular for the fusariosis of the ear of wheat,
• improve the management of hydrological risks and emergencies, enhancing hydrological modelling and forecasting capacity, in order to minimize economic losses due to floods.

Radar antenna in the Laboratory of Integration and Testing (LIE) of CONAE at the Space Center Teófilo Tabanera in Córdoba

Technical Characteristics

Other characteristics of SAOCOM 1A are detailed below:

The operating modes are classified as:

• Operational – satisfies all quality requirements and resolution specifications
• Technological – include technological innovations in order to evaluate improvements in performance
• Calibration – obtain measurements dedicated to the calibration of the SAR instrument and noise estimates

The available polarizations are:

The available acquisition modes are:

• StripMap, with Simple, Double or Quadruple (Full) polarization. In this mode, the radar points to a given fixed direction while capturing a continuous strip, which corresponds to the narrowest sweeps with the highest spatial resolution.
• TOPSAR Narrow, with Simple, Double or Quadruple (Complete) polarization. In this mode, the radar changes its pointing along the trace to capture several strips, thus covering a larger scan width with lower spatial resolution than in the StripMap case.
• TOPSAR Wide, with Simple, Double, Quad (Complete) or Compact polarization (technological mode). In this case, the radar changes its pointing along the trace to capture a greater number of strips, thus covering a wider sweep width with lower spatial resolution than in the TOPSAR Narrow case.

All acquisition modes in the Simple, Double and Quadruple (Full) polarization modes are operational. The TOPSAR Wide mode with Compact polarization corresponds to a technological mode.

SAOCOM 1A with the radar antenna deployed in CEATSA / INVAP
